Regular price$28.00
/

Type
  • Free worldwide shipping
  • In stock, ready to ship
  • Inventory on the way

Quick Details

Place of Origin:
Guangdong, China
Brand Name: Skydroid
Model Number: 3411
Private Mold:
NO
Type:
Drones Accessories
Product name:
HobbyWing X9 Max Drone Power System
Function:
Portable
OEM/ODM:
Warmly Welcomed
Lead Time:
Quantity(pieces) 1 - 200 201 - 5000 >5000
Est. Time(days) 15 40 To be negotiated
Products Description
3411 RC Drones Propeller Drone Parts Assembly And Accessories
For more style drone accessories, please contact us
Model Number
3411
Product Name
Drone Propeller
Suitable For
x9 motor
Diameter (Inch)
34
Pitch (Inch)
11
Weight (kg)
0.199
Color
Black
More Reference: Drone Propeller
Product Number
2388
3090
3411
36120
42136
Material
Plastic & Carbon Fiber
Plastic & Carbon Fiber
Plastic & Carbon Fiber
Plastic & Carbon Fiber
Plastic & Carbon Fiber
Matched Motor Brand
Hobbywing
Hobbywing
Hobbywing
Hobbywing
Torhang
Matched Motor PN
X6
X8
X9
X8, X9,X9+
X9 Max, X9+ Max
T28
Diameter (Inch)
23
30
34
36
42
Pitch (Inch)
8.8
9
11
12
13.6
Weight (kg)
0.1
0.126
0.199
0.21
0.25
More Reference: Drone Power System
Category
Product Item
X6
X8
X9
X9 Plus
X9 Max
Specifications
Max. Thrust per Axis (kg)
12
15.3
22.5
26.5
29
Recommended LiPo Battery
12S
12S
12~14S
14S
14S
Recommended Takeoff Weight per Axis (kg)
3-5
5-7
7-9.5
11~13
12-15
Combo Weight (g)
720
1040
1400
1774
1970
Waterproof Rating
IPX7
IPX7
IPX7
IPX7
IPX7
Motor
Stator Size (mm)
70
81*20
96*16
96*20
96*26
KV Rating (KV)
180
100
110
100
100
O.D of Carbon Fiber Tube with and W/O Tube Adapter
φ30/φ28
Φ35/Φ30
Φ40
φ40/φ45
φ40/φ45
Bearing
Imported Bearing
Imported Bearing
Imported Bearing
Imported Bearing
Imported Bearing
ESC
Recommended LiPo Battery
6-12S
6-12S
12-14S
6-14S
6-14S
PWM Input Signal Level
3.3v/5v (Compatible )
Throttle Signal Frequency
50-500Hz
Operating Pulse Width (Fixed or cannot be Programmed )
1100~1940 μs
1100~1940 μs
1100~1940 μs
1050-1950 μs
1050-1950 μs
Max. Input Voltage
52.2
52.2 V
52.2 V
60.9 V
60.9 V
Max. Input Current (A), Short Duration, Good Heat Dissipation
80
80 A
120 A
120 A
150 A
BEC
No
No
No
No
No
Nozzle Mounting Holes
φ28.4mm-2*M3
Recommended Propeller
Diameter×Pitch
2388
3090
3411
36190
36190
36190
